Description
4-Pole 100A Zigbee DIN circuit breaker with Energy Meter, Protection and Scheduling
✨ The ZCB-4P100M smart circuit breaker combines complete electrical protection with real-time consumption monitoring via Zigbee. Suitable for 50Hz, 230V/400V circuits, with protection against overload, short-circuit, overvoltage and undervoltage. 5+1+1 day scheduling.
✔ Overload, short-circuit, overvoltage and undervoltage protection ✔ Real-time energy meter: instantaneous, daily, weekly and monthly consumption ✔ Timer and 5+1+1 day scheduling (weekdays and weekend) ✔ Zigbee connection for smart home system integration ✔ Compatible with Tuya Smart / Smart Life app (iOS and Android) ✔ Compatible with Amazon Alexa and Google Home ✔ Installation on standard DIN rail ✔ Suitable for 50Hz, 230V/400V circuits, up to 100A ✔ Basic current: 0.2-100A ✔ 4 Poles for three-phase circuits + neutral
Usage Example
Install the circuit breaker in your three-phase electrical panel with neutral and connect it to the Zigbee gateway. Monitor the energy consumption of each phase in real-time through the Tuya Smart app. Set up schedules to turn off specific circuits at night or when you are not at home. Receive overload alerts or anomalies directly on your smartphone.
Product Specifications
Brand: MOES
Model: ZCB-4P100M
Poles: 4 Poles
Rated current: 100A
Basic current: 0.2-100A
Frequency: 50 Hz
Voltage: 230V/400V
Wireless connection: Zigbee
Protection: Overload, short-circuit, overvoltage, undervoltage
Scheduling: 5+1+1 day timer
Monitoring: Instantaneous, daily, weekly and monthly consumption
Installation: DIN rail
App: Tuya Smart / Smart Life (iOS and Android)
Compatible with: Amazon Alexa, Google Home
Weight: 0.7 kg
What's in the box
1x Zigbee DIN circuit breaker ZCB-4P100M
1x User manual
Barcode: 6974246472843
Reference: ZCB-4P100M
