Description
Shelly 2-Output Power Base for Wall Display - 2-Relay 5A Power Base
The Shelly 2-Output Power Base for Wall Display is a replaceable power base with two integrated relays, designed specifically for the Shelly Wall Display of the i series (X1i and X2i). This compact module allows the Wall Display not only to function as a control panel, but also to directly control two independent electrical circuits, such as lighting or other equipment.
It is installed on the back of the Wall Display, fitting perfectly into standard wall boxes. The two integrated relays allow up to two loads to be controlled remotely, automatically or on a schedule, with the Shelly Wall Display as the central interface.
Ideal for apartments, hotels, offices and smart homes where space and aesthetics matter, offering multifunctional control from a single wall unit.
Product features:
Brand: Shelly
Model: 2-Output Power Base for Wall Display
Compatibility: Shelly Wall Display X1i / X2i (i series)
Power supply: 100-240V AC, 50/60Hz
Number of outputs: 2 independent relays
Maximum switching voltage: 240V AC
Maximum current: 5A per channel
Auxiliary output: 5V DC / 1A
Material: Grey plastic
Connector color: Green
Dimensions: 72.30 x 69.80 x 28.70 mm
Weight: 53.5 g
Maximum torque: 0.4 Nm
Wire cross-section: 0.75 - 2.5 mm²
Operating temperature: -20°C to +40°C
Humidity: 30-70% RH
Installation: Standard wall box
Includes:
1 x Shelly 2-Output Power Base for Wall Display
1 x Installation guide
Barcode: 3800238072780
Reference: SH2OPBWD
