Shelly qubino z-wow 1pm Smart Module Z-Wave
O Shelly qubino wave 1pm It is a Z-Wave automation switch that allows the control and monitoring of the consumption of high power electrical appliances.
O Shelly qubino wave 1pm Works with tensions 110-240V AC or 24-30V DC and has a contact that supports current up to 16A .
O Shelly qubino wave 1pm works with Z-WAVE and can communicate perfectly with other devices that use this technology, regardless of your brand or platform, but, for this, a hub Centralized intelligent for this communication.
O Shelly qubino wave 1pm It is designed to be installed behind any switch or taking, transforming it instantly into a smart device. Once installed, include it on your Z-WAVE network and control the light-bound lights or devices from anywhere, using your smartphone or tablet.
Product characteristics:
Brand: Shelly
Model: Qubino Z-Wave 1pm
Food: 110-240V AC / 24-30V DC
Energy Consumption: 0.3 W
Contact Potential free: No (linked to phase)
Maximum switching voltage / AC: 240V / 16 A
Voltage / Maximum switching current DC: 30V / 10 A
CPU: Z-WAVE ™ S800 (System-in-Package)
Z-Wave Communication:
· Frequencies: Under-G (from 868.4 to 920.9 MHz)
· Z-Wave ™ repeater: yes
· Range: up to 40m in interior spaces (depends on local conditions)
Protection against overheating: yes
Driver's cross section: 0.5 to 1.5 mm² (20 to 16 AWG)
Enclosure Material: Plastic
Ambient temperature: -20 ° C to 40 ° C
Humidity: 30% to 70% hr
Include:
1 x shelly qubino wave 1pm
1x Instruction Manual
Bar Code: 3800235269022
Reference: Shzwave1pm
